GAUGE / ROOT VALVES
We are a Trusted Manufacturer, Supplier and Exporter of High Quality Gauge / Roots Valves used in Oil, Gas, Chemical, Petrochemical and Power industries. Our valves work well in critical applications such as Instrument Isolation, General Plant Service, Hydraulic & Pneumatic Line and Pressure Measurement Device Venting.
Our expert team is always available to guide you in selecting the perfect instrumentation valve to meet the needs of your industries.
AGRV
Gauge / Root Valves
Features:
- Available in SS 316
- Smoother operation
- Bar stock body design
- Self-cantering stem tip
Operating Range:
- Pressure : Up to 6000 psig (408 bar) at CWP
- Temperature : ‐40 °C to 220 °C with PTFE packing ‐40 °C to 420 °C with graphite packing
Connection & Size:
- Size : Pipe Thread 1/2” & 3/4"
- Connection : Male to Female end connections
Application:
- Venting
- Instrument isolation
- General plant service
- Hydraulic & Pneumatic line
- Pressure measurement device
